Hardware Descriptions
21
ProSAFE Wireless Controller
WC7500 and WC7600v2 Back Panel Components
The wireless controller comes with a single internal power supply and internal fans. The back
panel provides a Kensington™ lock slot and the AC power supply connector for the
100–240V, 3A, 50–60 Hz power supply.
Figure 3. Back panel models WC7500 and WC7600v2
Attach the power cord to the power supply connector. (The wireless controller does not
provide an on/off power switch.)
WC7500 and WC7600v2 Product Labels
The product label on the bottom of the wireless controller’s enclosure displays the default IP
address, default user name, and default password, as well as regulatory compliance, input
power, and other information.
Model WC7500 and model WC7600v2 share the same product label. The actual model
number (WC16A for both the WC7500 and the WC7600v2) is stated in the MODEL field.
Figure 4. Product label model WC7500 and model WC7600v2
Power supply connector
Kensington lock slot
