RF Planning and Deployment
87
ProSAFE Wireless Controller
Download a Report for an RF Plan
The report for an RF plan includes the following components:
• Floor summary
• Inventory summary that could serve as a purchase list
• Detailed list of access points
• Detailed list of antennas (if you added any manually)
• Floor map with suggested locations of the access points and antennas
• Heat map for the 2.4 GHz band
• Heat map for the 5 GHz band
You can download the report as a PDF or a Microsoft Word file.
 To generate and download a report for an RF plan:
1. Open a web browser, and in the browser’s address field, type the wireless controller’s IP
address.
By default, the IP address is 192.168.0.250.
The wireless controller’s login window opens.
2. Enter your user name and password.
3. Click the Login button.
The wireless controller’s web management interface opens and displays the Summary
page.
4. Select Plans > Planning.
The page displays the Planning icons.
5. In the building tree on the left, click the + icon of the building that contains the floor.
The floor names display.
6. Click the floor name.
The floor map displays.
7. Click the PDF icon or the Word icon.
The report downloads.
8. Follow the directions of your browser to save the report.
