ProSAFE Wireless Controller
Wireless Controller System Components
A wireless controller system consists of one or more wireless controllers and a collection of
access points that are organized into groups based on location or network access.
The wireless controller system can include a single wireless controller or a group of up to
three stacked wireless controllers that can function in a redundant configuration
1
.
The wireless controller system supports the following NETGEAR ProSAFE access point
models:
• WAC740 ProSAFE 4x4 Dual-Band Wireless AC Access Point
• WAC730 ProSAFE 3x3 Dual-Band Wireless AC Access Point
• WAC720 ProSAFE 2x2 Dual-Band Wireless AC Access Point
Stack Master LED
Note: Does not
apply to WC7500
Solid green The wireless controller is functioning as the master controller in
a stack.
Solid yellow The wireless controller is functioning as a slave controller in a
stack.
SFP slot LEDs
Note: Does not
apply to WC7500
and WC7600v2
Solid green The slot is operating at 10G.
Blinking green Data is being transmitted or received at 10G.
Solid yellow The slot is operating at 1G.
Blinking yellow Data is being transmitted or received at 1G.
Left Ethernet
port LED
Off The port is not connected to a powered-on Ethernet device
(see Ethernet Port LEDs Are Not Lit on page 361).
WC7500
and
WC7600v2
Solid green The port is operating at 1000 Mbps.
Blinking green Data is being transmitted or received at 1000 Mbps.
WC7600
and
WC9500
Solid green The port is operating at 1000 Mbps.
Solid yellow The port is operating at 100 Mbps or 10 Mbps.
Right Ethernet
port LED
Off The port is not connected to a powered-on Ethernet device
(see Ethernet Port LEDs Are Not Lit on page 361).
WC7500
and
WC7600v2
Solid yellow The port is operating at 100 Mbps or 10 Mbps.
Blinking yellow Data is being transmitted or received at 100 Mbps or 10 Mbps.
WC7600
and
WC9500
Solid green The port is connected to a powered-on Ethernet device.
Blinking green Data is being transmitted or received.
1. Model WC7500 does not support stacking and redundancy.
Table 5. LED functions for all models (continued)
LED Status Description
