4.10 Response Calibration

BP4610

4-72

4.10.2 Fixed characteristics

The fixed characteristics emphasize both wide frequency band characteristics and load stability (during

CV: DC to 35 kHz, −3 dB; during CC: DC to 8 kHz, −3 dB).

 Operation procedure

<1> Press the

and keys to move the cursor to the icon.

ENTERCANCEL

<2> Press the

ENTER

key to display the Select box.

ENTERCANCEL

<3> Press the

and keys to move the cursor to “OFF”.

ENTERCANCEL

<4> Press the

ENTER

key to set the response calibrator to off.
