4.1 LCD Screen

BP4610

4-3

4.1.2 Warning and error display

Upon occurrence of a warning or error, an error message is displayed in the message box and Message

Display window.

For details on error messages,

refer to “6 TROUBLESHOOTING”.

4.1.3 Sequence display

The BP4610 has a function to display the sequence progress status. The information listed in Table 4-2

is displayed in the message box.

Table 4-2. Sequence Display

Message Description Remark

SEQUENCE: RUNNING/STEP *** Sequence in progress

*** indicates the step number currently being

run.

SEQUENCE: HOLDING/STEP *** Sequence hold in progress *** indicates the step number that is on hold.

SEQUENCE: FINISH Sequence end This message automatically disappears after 2 s.
