8.3 Output Limiters
BP4610
8-4
8.3 Output Limiters
Output voltage limiters
+ voltage setting range: +7 V to +117 V (0.1 V resolution) (+Vo limit)
− voltage setting range: −7 V to −117 V (0.1 V resolution) (−Vo limit)
Restrictions: The difference between the + voltage setting and the – voltage
setting is restricted to 24 V or higher and 124 or lower.
Setting accuracy: ±1 V (DC)
Remark: The output voltage and output current supply ranges are
determined by the output voltage limiter settings. (
Refer to
“8.18 Output Voltage and Output Current Supply Ranges”.)
Depending on the operation conditions, the output voltage may be
limited to a narrower range than the voltage limiter settings. (
Refer to “8.18 Output Voltage and Output Current Supply
Ranges”.)
Output current limiters
+ current setting range: +1 A to +26 A (0.1 A resolution) (+Io limit)
− current setting range: −1 A to −26 A (0.1 A resolution) (−Io limit)
Setting accuracy: ±1 A (for DC within ±10 A)
Remark: The source current is considered to be positive.
Depending on the operation conditions, the output current may be
limited to a narrower range than the current limiter settings. (
Refer to “8.18 Output Voltage and Output Current Supply
Ranges”.)
