4.5 Sequence Operation
BP4610
4-38
Table 4-18. PROGRAM Screen Item List
Item Name Item Operation
STEP Step No.
Specifies the step number to be set.
Setting range: 1 to 255
TIME Step time
Specifies the duration of the specified step.
Setting range: 0.0001 s to 999.9999 s
Setting resolution: 0.0001 s
DC VOLT DC voltage
Sets the DC voltage in the CV mode.
Setting range: −115.00 V to 115.00 V
Setting resolution: 0.01 V
DC CUR DC current
Sets the DC current value in the CC mode.
Setting range: −10.000 A to 10.000 A
Setting resolution: 0.001 A
−
DC voltage/DC current
operation type
Sets the type of transition to the specified DC voltage value and DC
current value. The type of transition can be selected from the following
three.
• CONST: Output of the specified value
• KEEP: Output of the last value of the previous step
• SWEEP: Output started with the last value of the preceding step,
with linear sweep outputting the specified value at the end
of the step
AC VOLT Superimposed AC voltage
Sets the superimposed AC voltage value in the CV mode.
Setting range: 0.0 Vp-p to 120.0 Vp-p
Setting range: 0.1 Vp-p
AC CUR Superimposed AC voltage
Sets the superimposed AC voltage value in the CC mode.
Setting range: 0.00 Ap-p to 30.00 Ap-p
Setting range: 0.01 Ap-p
−
Superimposed AC
voltage/superimposed AC
current operation type
Sets the type of transition to the specified superimposed AC voltage
value and superimposed AC current value. The type of transition can be
selected from the following three.
• CONST: Output of the specified value
• KEEP: Output of the last value of the previous step
• SWEEP: Output started with the last value of the preceding step,
with linear sweep outputting the specified value at the end
of the step
FREQ Frequency
Sets the superimposed AC frequency.
Setting range: 1.0 Hz to 100000.0 Hz
Setting resolution: 0.1 Hz
−
Frequency operation type
Sets the type of transition to the specified frequency. The type of
transition can be selected from the following three.
• CONST: Output of the specified value
• KEEP: Output of the last value of the previous step
• SWEEP: Output started with the last value of the preceding step,
with linear sweep outputting the specified value at the end
of the step
WAVE Waveform Selects the arbitrary waveform to be output.
Setting range: ARB1 to ARB16
−
Frequency operation type Selects the type of transition to the specified waveform. The type of
transition can be selected from the following three.
• CONST: Output of the specified waveform
• KEEP: Output of the waveform of the previous step
To Next Page
