4.5 Sequence Operation
BP4610
4-28
 Sequence
A sequence consists of two or more steps, with the minimum unit constituting one step. The
superimposed AC phase is continuous as steps change.
 Step
Step execution and step transition parameters are described for each step. Even in the status where
no sequence is being executed, in other words regular output, the same parameters as for steps are
held. These parameters are subsequently used as regular output steps. In the following description,
step parameters are enclosed in [ ].
The step execution parameters specify the output and its behavior.
Table 4-13. Step Execution Parameters
[Output parameters]
• DC voltage (current)
• Superimposed AC voltage (current)
• Frequency
• Waveform (ARB only)
• Step sync output
[Step operation types]
The following items are provided as output behavior specifications for each
step.
• Constant (CONST)
• Sweep (SWEEP)
• Output using end value of previous step (KEEP)
Note
Note If KEEP is selected for [Step operation type], the [Output parameters] settings are ignored.
