NF BP4610 - Figure 4-11. DC Output Range (When Negative Voltage Limiter Setting Is Fixed to −7 V)

4.4 Setting of limiters
BP4610
4-25
+Vo −Vo
limit limit
(V) (V)
<1> +117 −7
<2> +102 −7
<3> +82 −7
<4> +62 −7
<5> +42 −7
<6> +22 −7
Figure 4-11. DC Output Range (When Negative Voltage Limiter Setting Is Fixed to −7 V)
If the BP4610 is to emphasize the 2nd quadrant or 4th quadrants taking in power (to maximize the take-
in power amount), lower the negative voltage limiter as much as possible for the 2nd quadrant, or the
positive voltage limiter for the 4th quadrant.
DC output range
−20
−10
0
10
20
30
40
50
60
70
80
90
100
110
120
−11
−10
−9
−8 −7 −6 −5 −4 −3 −2
−1
0 1 2 3 4 5 6 7 8 9 10
11
Io (A)
Vo ( V )
<1>
<2>
<3>
<4>
<5>
<6>
When fixed to [−Vo limit] = −7 V
