6.1 Error Messages
BP4610
6-1
6.1 Error Messages
The BP4610 runs a self-diagnosis at power-on, and if an anomaly is detected, an error message is
displayed. An error message is also displayed when an incorrect setting or operation is performed.
The contents and cause of the error message, as well as the required handling, are listed below.
6.1.1 Error at power-on
The BP4610 performs the following fault diagnoses at power-on.
If an error occurs, “NG” is displayed on the system check screen.
Table 6-1 lists the diagnosis items and the required handlings in case of fault detection.
Table 6-1. Self-Diagnosis Errors
Fault Diagnosis Item Fault Contents Operation at Fault Detection & Required Handling
ROM CHECK ROM sum-check
RAM READ/WRITE CHECK RAM read and write check
Product failure may have occurred. Contact NF
Corporation or an NF Corporation sales
representative.
The operation stops at this point and the error
remains displayed until the power is switched off.
BACKUP MEMORY CHECK Backup memory sum-check
WAVE MEMORY CHECK Waveform memory sum-check
SEQUENCE MEMORY
CHECK
Sequence memory sum-check
VERSION CHECK Version number check
The BP4610 starts after memory initialization is
completed.
(
Refer to “9. INITIAL SETTING LIST”.)
These errors may occur when the BP4610 has been
stored for a long time without being powered on.
However, if such errors occur with high frequency,
the characteristics of the backup battery may have
become degraded.
(
Refer to “7.6 Backup Battery”.)
CALIBRATION MEMORY
CHECK
Calibration value memory sum-
check
The BP4610 starts after calibration value memory
initialization has been completed.
In this case, the BP4610 starts up without calibration
values, and therefore the prescribed performance
cannot be obtained. Since there may be defective
parts, contact NF Corporation or an NF Corporation
sales representative.
 Examples of screen displays in case of fault detection during self-diagnosis
ROM CHECK ......................................... OK
RAM READ/WRITE CHECK................. OK
BACKUP MEMORY CHECK ................ OK
WAVE MEMORY CHECK ..................... OK
SEQUENCE MEMORY CHECK ............ OK
CALIBRATION MEMORY CHECK ...... NG ….. INITIALIZED
VERSION CHECK ................................. NG ….. INITIALIZED
