2.4 Connection to I/O terminals
BP4610
2-9
Table 2-2. External Control I/O Connector Pin List
Pin No. I/O Function Remark
1 Output Power on/off status
0: Off
1: On
2 Output Output on/off status
0: Off
1: On
3 Output Overload
0: Normal
1: Overload
4 Output Software busy
0: Normal
1: Busy
5 Output Step sync output 0
6 Output Step sync output 1
7 Output Undefined
8 Output Undefined
9 GND
−
10 Input Undefined
11 Input Forced output off Falling edge detection
12 Input Forced output on Falling edge detection
13 Input Sequence start Falling edge detection
14 Input Sequence stop Falling edge detection
15 Input Sequence hold Falling edge detection
16 Input Sequence branch trigger 0 Falling edge detection
17 Input Sequence branch trigger 1 Falling edge detection
18 GND
−
19 +5 V
−
50 mA or lower
20 Output Reserved
21 Output Reserved
22 Output Reserved
23 GND
−
24 Output Reserved
25 GND
−
