5.2 Program Message List
BP4610
5-5
(2/2)
Header Function Max. Value Min. Value Resolution Setting Query
7th parameter
Jump count
0: Infinite count
1 to 999: Specified count
√ √
8th parameter
Branch 0
0: Branch disabled
1 to 255: Step number
√ √
STRP Step transition parameters
9th parameter
Branch 1
0: Branch disabled
1 to 255: Step number
√ √
SCTL Sequence control
0: Stop
1: Start
2: Hold
3: Branch 0
4: Branch 1
4 0 1
√
−
SSTS? Sequence status
0: Idle status
1: Run status
2: Hold status
2 0 1
−
√
SCSN? Acquires step number during execution 255 −1 1
−
√
SCJN? Acquires jump count of specified step number 999 −1 1
−
√
SEQM Sequence memory control 0: Clear 0 0 1
√
−
 SCSN? return value –1 indicates that the sequence status is Idle. 0 is an unused number.
 SCJN? return value –1 indicates that the sequence status is Idle.
Table 5-4. Measurement Related
Header Function Max. Value Min. Value Resolution Setting Query
MVLT? DC voltage measurement value
200.0
(999.9)
−200.0 0.1
−
√
MACV? AC voltage measurement value
400
(999)
0 1
−
√
MCUR? DC current measurement value
20.00
(99.99)
−20.00 0.01
−
√
MACC? AC current measurement value
40.0
(99.9)
0.0 0.1
−
√
The figures in parentheses ( ) are the values of response messages when measurement over-range
occurs.
！
