5.2 Program Message List
BP4610
5-4
Table 5-3. Sequence Related
(1/2)
Header Function Max. Value Min. Value Resolution Setting Query
SLEN? Specifies sequence length Fixed to 255
− √
STPN Specifies step number 255 1 1
√ √
1st parameter DC voltage/DC current
√ √
2nd parameter
DC voltage/DC current operation type
0: CONST/1: KEEP/2: SWEEP
√ √
3rd parameter
Superimposed AC voltage/
superimposed AC current
√ √
4th parameter
Superimposed AC voltage/
superimposed AC current operation
type
0: CONST/1: KEEP/2: SWEEP
√ √
5th parameter Frequency
√ √
6th parameter
Frequency operation type
0: CONST/1: KEEP/2: SWEEP
√ √
7th parameter
Waveform
2 to 17: ARB1 to ARB16
√ √
8th parameter
Waveform operation type
0: CONST/1: KEEP
√ √
9th parameter
Step sync output
0: (0,0)/1: (0,1)/
2: (1,0)/3: (1,1)
√ √
SEXP Step execution parameters
10th parameter
Step sync output operation type
0: CONST/1: KEEP
√ √
1st parameter
Step time mode
Fixed to 0
√ √
2nd parameter Step time
√ √
3rd parameter
Step end phase enable/disable
0: Disable/1: Enable
√ √
4th parameter
Step end phase
Fixed to 0 deg
√ √
5th parameter
Step termination
0: Continue sequence
1: Enter Idle status
2: Enter Hold status
√ √
STRP Step transition parameters
6th parameter
Jump step
0: Go to next step number
1 to 255: Step number
√ √
