5.2 Program Message List
BP4610
5-3
Table 5-1. Basic Settings
Header Function Max. Value Min. Value Resolution Setting Query
MODE Function mode
0: CV-INT
1: CV-EXT
2: CV-ADD
3: CC-INT
4: CC-EXT
5: CC-ADD
5 0 1
√ √
OUTP Output on/off
0: Off
1: On
1 0 1
√ √
RCAL
Response calibrator
on/off
0: Off
1: On
1 0 1
√ √
VOLT DC voltage 115.00 −115.00 0.01
√ √
ACVL Superimposed AC voltage 120.0 0.0 0.1
√ √
CURR Output current 10.000 −10.000 0.001
√ √
ACCU Superimposed AC current 30.00 0.00 0.01
√ √
FREQ Superimposed AC frequency 100000.0 1.0 0.1
√ √
WAVE
Superimposed AC
waveform
0: SIN
1: SQU
2 to 17: ARB1 to
ARB16
17 0
√ √ √
Table 5-2. Limiters
Header Function Max. Value Min. Value Resolution Setting Query
LMVP + voltage limiter 117.0 7.0 0.1
√ √
LMVM − voltage limiter −7.0 −117.0 0.1
√ √
LMCP + current limiter 26.00 1.00 0.1
√ √
LMCM − current limiter −1.00 −26.00 0.1
√ √
