NF BP4610 - Table 5-5. Arbitrary Waveform Memory; Table 5-6. Memory; Table 5-7. Status Reporting

5.2 Program Message List
BP4610
5-6
Table 5-5. Arbitrary Waveform Memory
Header Function Max. Value Min. Value Resolution Setting Query
ARBN
Specifies transmit/receive arbitrary waveform
memory
17 2 1
√ √
ARBT Arbitrary waveform transmission/reception
#42048
[Data] … … …
Data is in 2’s complement format.
√ √
ARBM
Arbitrary waveform memory
control
0: Clear
0 0 1
√
−
 Partial reading of an arbitrary waveform is not possible.
 When arbitrary waveforms are cleared, sine waves, square waves, and triangular waves are written to
ARB1 to ARB8, ARB9 to ARB12, and ARB13 to ARB16, respectively.
Table 5-6. Memory
Header Function Max. Value Min. Value Resolution Setting Query
*SAV Store memory 30 1 1
√
−
*RCL Recall memory 30 1 1
√
−
Table 5-7. Status Reporting
Header Function Max. Value Min. Value Resolution Setting Query
*STB?
Status byte
255 0 1
−
√
*SRE
SRQ enable register
255 0 1
√
√
*ESR?
Standard event status register
255 0 1
−
√
*ESE
Standard event status enable register
255 0 1
√
√
OPCR?
Operation condition register
32767 0 1
−
√
OPTF
Operation transition filter
32767 0 1
√
√
OPER?
Operation event register
32767 0 1
−
√
OPEE
Operation event enable register
32767 0 1
√
√
WRER?
Warning event register
32767 0 1
−
√
WREE
Warning event enable register
32767 0 1
√
√
OVCR?
Overload condition register
32767 0 1
−
√
OVTF
Overload transition filter
32767 0 1
√
√
OVER? Overload event register 32767 0 1
−
√
OVEE Overload event enable register 32767 0 1
√ √
*CLS Event register content clear
− − −
√
−
！
CAUTION
