5.3 Explanation of Each Program Message
BP4610
5-21
■ *RST
Description: Resets the device.
Caution: This operation cannot be performed while output is on.
Refer to 9 “INITIAL SETTING LIST”.
■ *TST?
Description: Self test. Self-diagnosis result is returned at power-on.
The diagnosis result is returned as 16-bit data. The higher 8 bits and lower 2
bits are fixed to 0, so judge errors based on the values of bits 2 to 7.
Response format: 0: No error
Other than 0: Error occurrence
Bit 7: The backup, waveform, and sequence memories have been
initialized due to version upgrade.
Bit 6: Not calibrated or initialized without calibration value.
Bit 5: Calibration defect or initialized without calibration value.
Bit 4: Initialized due to sequence memory defect
Bit 3: Initialized due to waveform memory defect
Bit 2: Initialized due to backup memory defect
■ VERS?
Description: Queries the version number.
Response example: 1.00
■ XCTL/XCTL?
Description: Sets external control input enable/disable.
Parameter: 0: Disable
1: Enable
Setting example: Enabling external control input
XCTL 1
