7.8 Performance Test
BP4610
7-14
DC output voltage measurement accuracy test
Load: No load
Measurement connection: Measure the voltage of the output terminal of the BP4610 with a
DC voltmeter.
Settings: After setting initialization has been performed, set the output voltage limiters and
current output voltage according to the following table.
Judgment: If the difference between the DC voltage measurement display value of the
BP4610 and the value measured with the DC voltmeter falls within the rated ranges in the
following table, the operation is judged to be normal.
+ Voltage Limiter Setting − Voltage Limiter Setting DC Output Voltage Setting Rated Range
+117 V −7 V +115 V −0.5 to +0.5 V
+7 V −117 V −115 V −0.5 to +0.5 V
DC output current measurement accuracy test
Load: Short via a current shunt resistor
Measurement connection: Measure the detection voltage of the current shunt resistor with a
DC voltmeter and convert the measured value to a DC value.
Settings: After setting initialization has been performed, set the operation mode and the DC
output current according to the following table.
Judgment: If the difference between the DC current measurement display value of the
BP4610 and the current value measured with the DC voltmeter falls within the rated ranges in
the following table, the operation is judged to be normal.
Operation Mode Setting DC Output Current Setting Rated Range
+10 A −0.1 to +0.1 A CC-INT
−10 A −0.1 to +0.1 A
