3.1 Nomenclature
BP4610
3-4
<14> MONITOR OUT−Io
This is the current monitor output terminal.
Refer to “2.4.6 Connection to monitor output terminal”.
<15> T volume
This volume is used to adjust the time constant.
Refer to “4.10 Response Calibration”.
<16> V volume
This volume is used to adjust the voltage feedback amount.
Refer to “4.10 Response Calibration”.
<17> I volume
This volume is used to adjust the current feedback amount.
Refer to “4.10 Response Calibration”.
