3-55
Note 1. Do not set n001 to any value other than the above.
Note 2. Refer to n035 on
page 3-66
for the 3-wire sequence.
n002 Operation Mode Selection
Setting range 0 to 3 Unit --- Default setting 3
• The
Inverter has four operation modes. Refer to the following table
and select one of the modes with
n002.
Set Values
Set
value
Run command Frequency reference
Operation mode indicator of Digital
Operator
Remote operation Analog input
0 Digital Operator
(RUN/STOP Key)
Digital Operator
(Frequency reference 1)
Not lit Not lit
1 Control circuit terminals
(Forward/reverse/stop
input)
Digital Operator
(Frequency reference 1)
Lit Not lit
2 Digital Operator
(RUN/STOP Key)
Control circuit terminals
(Analog input)
(see note 2)
Not lit Lit
3 Control circuit terminals
(Forward/reverse/stop
input)
Control circuit terminals
(Analog input)
(see note 2)
Lit Lit
Note 1. Do not set n002 to any value other than the above.
Note 2. The
frequency reference input according to the operation mode selection setting
will be used
as frequency reference 1 in multi-step step speed operation. If the frequency reference is
determined
by control circuit
terminals, the frequency reference input using the control circuit
terminals’ analog input will be enabled and the frequency reference 1 parameter setting
(n025) will be ignored. (If, however, the mode is changed to Local mode using the Digital
Operator, then the value set in n025 will be enabled.)
Note 3. Frequency
references 2 to 4 (n026
to n028) and the inching frequency reference (n029) used
in
multi-step speed operation will be determined by the parameter settings, regardless of the
operation mode selection setting.
n003 Input Voltage Selection
Setting range 150.0 to 255.0
(510.0)
Unit --- Default setting 200.0 (400.0)
Note The figures in the parentheses apply to the 400-V Inverter.
• Set the input voltage of the Inverter to determine the voltage protection level of the Inverter.
n004 Interruption Mode Selection
Setting range 0 to 3 Unit --- Default setting 0
Preparing for Operation Chapter 3
