3-27
200-V class 400-V class
Capacity of motor (kW) Energy-saving
coefficient K2 (n096)
Capacity of motor (kW) Energy-saving
coefficient K2 (n096)
0.4 288.2 0.4 576.4
0.75 223.7 0.75 447.4
1.5 169.4 1.5 338.8
2.2 156.8 2.2 313.6
3.7 122.9 3.7 245.8
5.5 94.75 5.5 189.5
7.5 72.69 7.5 145.4
11 70.44 11 140.9
15 63.13 15 126.3
18 57.87 18 115.7
22 51.79 22 103.6
30 46.27 30 92.54
37 38.16 37 76.32
45 35.78 45 71.56
55 31.35 55 67.20
75 23.10 75 46.20
--- --- 110 36.23
160 30.13
185 30.57
220 27.13
300 21.76
Note 1. The
above K2 values are for standard motors and dedicated motors for inverters. The Inverter
in
energy-saving mode cannot save unnecessary power supply to
high-speed motors (e.g.,
spindle
motors) or any other motor that has an ef
ficiency curve with more than one peak (e.g.,
any double squirrel-cage motor).
Note 2. The
Inverter performs energy-saving control at 15 to 120 Hz. The Inverter does not perform
energy-saving control at a frequency exceeding 120 Hz.
n100 Search Control Voltage Limit
Setting range 0 to 100 Unit % (Rated input
voltage ratio of
motor)
Default setting 0
Set Values
S Set
the range of the variable voltage of the Inverter in search operation mode with 1% units based
on the rated input voltage of the motor set with n011 as 100%.
S The value of n100 is usually set to a range from 0 to 20%. Usually n100 is set to 10%.
S The search operation will not be available if n100 is set to 0.
n097 Energy-saving Voltage Lower Limit for 60 Hz
Setting range 0 to 120 Unit % (Rated input
voltage ratio of
motor)
Default setting 50
Preparing for Operation Chapter 3
To Next Page
