About this Manual
This manual is divided into the chapters described in the following table. Information is organized by
application area to enable you to use the manual more efficiently.
Chapter Contents
Chapter 1 Introduction Describes functions and nomenclature.
Chapter 2 Installation Provides dimensions, installation methods, and wiring methods.
Chapter 3 Preparing for Operation Describes procedures required for preparing the Inverter and Digital
Operator for operation. It is divided into the following areas:
Preparation Procedure
Outlines the procedures required to use the Inverter from purchase
right up to actual operation.
Using the Digital Operator
Describes the nomenclature, operating methods, such as Digital
Operator key operations, and monitor functions.
Test Run
Describes how to perform a test run using the Digital Operator to
confirm operation for the Inverter and the system in which it is to be
used.
Basic Operation
Describes the functions used for the basic control. The functions
described here are the minimum required for running a motor with an
Inverter.
Applied Operation
Describes all the applied functions that are available with the Inverter.
This includes explanations for functions that can be used to improve
the responsiveness (torque characteristic) and the speed accuracy, as
well as additional functions such as PID control and overtorque
detection.
Chapter 4 Operation Provides information related to Inverter maintenance. This includes
possible causes and countermeasures for errors, as well as inspection
procedures.
Chapter 5 Specifications Provides Inverter specifications, as well as the specifications and
dimensions of peripheral devices.
Chapter 6 Appendix Provides notes on using the Inverter on a motor and gives a list of
standard models. It also provides ordered lists of parameters for easy
reference. The parameter lists include page references.
