3-84
n059 Jump Frequency 2
Setting range 0.0 to 400.0 Unit Hz Default setting 0.0
n060 Jump Frequency Range
Setting range 0.0 to 25.5 Unit Hz Default setting 1.0
• The
frequency jump prevents the Inverter from generating frequencies that make the mechanical sys
-
tem resonate.
• The frequency jump can be used effectively to make dead bands for frequency references.
• Set with n058 and n059 the center values of jumping frequencies.
• The
value set with n059 must be as large as or larger than the value set with n059, otherwise OPE6
(improper parameter setting) will result.
• Set with n060 a jump frequency width.
Output
frequency
Frequency
reference
n061 Total Operating Time Function Selection
Setting range 0, 1 Unit --- Default setting 1
n062 Total Operating Time 1 (Rightmost 4 Digits)
Setting range 0 to 9,999 Unit h Default setting 0
n063 Total Operating Time 2 (Leftmost 2 Digits)
Setting range 0 to 27 Unit x 10,000 h Default setting 0
• Select
with n061 whether to permit the Inverter to accumulate the power-ON
time or operation time of
the Inverter.
Set Values (n061)
Set value Description
0 Accumulates power-ON time
1 Accumulates operation time
• Set
with n062 and n063 the initial operation time
of the Inverter
. The accumulated operation time of the
Inverter can be obtained from the following.
Accumulated operation time (h) = n063 x 10,000 + n062
• The
parameters n062 and n063 can be used to monitor the accumulated operation time of the Inverter
.
• The
maximum value of the accumulated operation time set with n062 and n063 is
279620 (h). When
the value of the accumulated operation time exceeds 279620, n062 and n063 will be set to 0.
Preparing for Operation Chapter 3
