Appearance 2
4-J: Mounting bolts
Mounting hole
M: Terminal
Nameplate
5-2-10 Simple Input Noise Filter and Input Noise Filter
H 3G3EV-PLNFDj (Yaskawa Electric)/3G3IV-PFNj (Schaffner)
The Simple Input Noise Filter is connected
to
the power input side to eliminate the noise
in the power line connected to the Inverter
and suppress noise leaking from the
Inverter to the power line.
Simple Input Noise Filter Input Noise Filter
Specifications Chapter 5
