3-40
3-5-3 List of Parameters
Values in brackets [ ] are default-set values.
Note Parameters that can be changed while the Inverter is running are indicated in bold type.
H Group 1: n001 to n034
Function No. Name Description Setting
range
Refer-
ence
page
Parameter
group selection
n001 Parameter
write prohibit
selection/Pa-
rameter initial-
ization
0: The parameters n001 can be set and
checked and the parameters n002 to
n108 can be only checked.
The speed and direction of the Digital
Operator can be set.)
1: The parameters of group 1 (i.e., n001
to n034) can be set and checked and
the parameters of groups 2 and 3 (i.e.,
n035 to n049 and n050 to n108) can be
only checked.
2: The parameters of groups 1 and 2 can
be set and checked and the parame-
ters of grou
p
3 can only be checked
0 to 7
[1]
3-13
Parameter ini-
tialization
t
ers o
f
group
3
can on
l
y
b
e c
h
ec
k
e
d
.
3: The parameters of groups 1, 2, and 3
can be set and checked.
6: All parameters will be set to default-set
values.
7: All parameters will be initialized with a
three-wire sequence.
Note When parameter initialization is per-
formed by setting to 6 or 7, the For-
ward/Reverse rotation selection
(n005) is not initialized. (It is only ini-
tialized when a CPF4 error is
detected.)
Operation
mode selection
n002 Operation
mode selection
Selects method to input run command and
frequency reference.
Run command Frequency reference
0: Digital Operator Digital Operator
1:
Control
circuit terminals
Digital Operator
2: Digital Operator Control circuit terminals
3:
Control
circuit terminals
Control circuit terminals
0 to 3
[3]
3-13
Input voltage
selection
n003 Input voltage
selection
(see note)
Set Inverter input voltage in 1-V units. 150.0
to
255.0
[200.0]
3-23
Interruption
mode selection
n004 Interruption
mode selection
0: Deceleration stop
1: Free running stop
2: Free running stop 1 with timer. The run
command during deceleration time 1 or
2 will be ignored.
3: Free running stop 2 with timer. The
constant run command is valid. The
motor will start running after decelera-
tion time 1 or 2 passes.
0 to 3
[0]
3-23
Note With
400-V Inverters, the setting range
upper limits and default settings are double those shown
in the table.
Preparing for Operation Chapter 3
