3-24
S Set the rated input current of the motor with n032 and the electronic thermal protective function
with n033 to determine the motor protective characteristics.
n032 Motor Rated Current
Setting range See note 1 Unit --- Default setting 1
Note 1. The set value range is from 10% to 200% of the rated output current.
Note 2. The default-set value varies with the Inverter model.
Note 3. Be sure to set n032 after checking the rated input current of the motor.
n033 Electronic Thermal Protection Function Selection
Setting range 0 to 4 Unit --- Default setting 1
Set Values
Set value Description
0 No protection.
1 For standard motors with standard ratings (with a time constant of 8 min).
2 For standard motors with short-time ratings (with a time constant of 5 min).
3 For dedicated motors with standard ratings (with a time constant of 8 min).
4 For dedicated motors with short-time ratings (with a time constant of 5 min).
Preparing for Operation Chapter 3
