1-1 Function
The 3G3HV High-capacity General-purpose Inverter is an easy-to-use inverter that has
advanced features, such as PID control and energy-saving operations.
H SYSDRIVE 3G3HV Inverter Models
• The following 200- and 400-V class 3G3HV Inverter models are available.
• A
total of 21 types of Inverter are available for maximum applicable motor capacities of 0.4 to 300 kW .
Voltage class Protective structure Maximum applied motor
capacity
Model
200-V Class
(h)
NEMA1 type
3.7 kW 3G3HV-A2037-E
(3-phase)
y
5.5 kW 3G3HV-A2055-E
7.5 kW 3G3HV-A2075-E
11 kW 3G3HV-A2110-E
15 kW 3G3HV-A2150-E
Open chassis type
18.5 kW 3G3HV-B2185-E
y
22 kW 3G3HV-B2220-E
30 kW 3G3HV-B2300-E
37 kW 3G3HV-B2370-E
45 kW 3G3HV-B2450-E
55 kW 3G3HV-B2550-E
75 kW 3G3HV-B2750-E
400-V Class
()
NEMA1 type
3.7 kW 3G3HV-A4037-E
(3-phase)
y
5.5 kW 3G3HV-A4055-E
7.5 kW 3G3HV-A4075-E
11 kW 3G3HV-A4110-E
15 kW 3G3HV-A4150-E
Open chassis type
18.5 kW 3G3HV-B4185-E
y
22 kW 3G3HV-B4220-E
30 kW 3G3HV-B4300-E
37 kW 3G3HV-B4370-E
45 kW 3G3HV-B4450-E
55 kW 3G3HV-B4550-E
75 kW 3G3HV-B4750-E
110 kW 3G3HV-B411K-E
160 kW 3G3HV-B416K-E
185 kW 3G3HV-B418K-E
220 kW 3G3HV-B422K-E
300 kW 3G3HV-B430K-E
Introduction Chapter 1
