3-16
n027 Frequency Reference 3
Setting range 0 to maximum
frequency
Unit Set with n024 Default setting 0.0
n028 Frequency Reference 4
Setting range 0 to maximum
frequency
Unit Set with n024 Default setting 0.0
S The inching frequency reference must be set with n029 if an inching frequency is required. The
inching
command must be selected to use the inching frequency reference. Refer to
page
3-17,
Multi-function Input Selection (n035 to n039)
for details.
n029 Inching Frequency Reference
Setting range 0 to maximum
frequency
Unit Set with n024 Default setting 6.0
H Acceleration/Deceleration Time Selection (n019 to n022)
S Acceleration time and deceleration time can be set with n019 to n022.
S The
acceleration/deceleration time
switching command must be selected to use acceleration time
2 and deceleration time 2. Refer to
page 3-17, Multi-function Input Selection (n035 to n039)
for
details.
n019 Acceleration Time 1
Setting range 0.0 to 3,600 Unit s Default setting 10.0
n020 Deceleration Time 1
Setting range 0.0 to 3,600 Unit s Default setting 10.0
n021 Acceleration Time 2
Setting range 0.0 to 3,600 Unit s Default setting 10.0
n022 Deceleration Time 2
Setting range 0.0 to 3,600 Unit s Default setting 10.0
Set Values
S Acceleration time: The
time required for the output
frequency to be 100% from 0% of the maxi
-
mum frequency.
S Deceleration time: The
time required for the output
frequency to be 0% from 100% of the maxi
-
mum frequency.
S Acceleration time 2 and deceleration time 2 is available if the acceleration/deceleration time
switching command is set.
H Motor Rotation Direction Selection (n005 and n006)
S Set the rotation direction of the motor with n005 so that the motor will rotate in the set direction
when the forward rotation command is input.
Preparing for Operation Chapter 3
