2-7
D Digital Operator Installation
Panel cutout
(for cables)
Two, 4 dia.
Panel face
Front side of panel
Back side of panel
30 min.
4
125
4
27
88
16
39
18.8
2-1-2 Installation Conditions
H Cautions and Warnings
WARNING Provide an appropriate stopping device on the machine side to secure safety. (A
holding
brake is
not a stopping device for securing safety
.) Not doing so may result in
injury.
WARNING Provide
an external emergency stopping device that
allows an instantaneous stop of
operation and power interruption. Not doing so may result in injury.
Caution Be sure to install the product in the correct direction and provide specified clear-
ances between the Inverter and control panel or with other devices. Not doing so
may result in fire or malfunction.
Caution Do
not allow foreign objects to
enter inside the product. Doing so may result in fire or
malfunction.
Caution Do not apply any strong impact. Doing so may result in damage to the product or
malfunction.
Installation Chapter 2
