Note 4. If n109 is set to 0.0, the slip compensation function will be disabled.
Note 5. Set the motor’s rated frequency in n014.
n112 Operation Selection at Digital Operator interruption
Setting range 0, 1 Unit --- Default setting 0
Set Values
Set value Description
0 Digital Operator disconnection detection disabled
1 Digital Operator disconnection detection enabled
• This function can be used to detect a disconnection with the Digital Operator.
• When
n1
12 is set to 1, if a disconnection with the Digital Operator is detected while the Inverter is run
-
ning, an
%pr error will be displayed and the motor will coast to a stop.
n113 Frequency detection width
Setting range 0.0 to 25.5 Unit Hz Default setting 2.0
• Set the detection widths for frequency agreement (set value: 2), optional frequency agreement (set
value:
3), and optional frequency detection (set values: 4, 5) for multi-function inputs
1 to 5 (n035 to
n039).
Frequency agreement, optional frequency agreement: Detection width = Value set for n113
Release
width = T
wice value set for
n1
13
Optional frequency detection: Release width = Value set for n113
n114 Operation Selection at Operation Mode Switching
(local/remote switching)
Setting range 0, 1 Unit --- Default setting 0
Set Values
Set value Description
0 Run signals that are input during mode switching are ignored. (Input run signals after switching
the mode.)
1 Run signals become effective immediately after switching to the Remote mode. (Operation after
the mode has switched will be determined by the status of the run signal at that time.)
• Select
whether or not to ignore run signals input while the operation mode is switched using the Operation
Mode
Selection Key on the Digital Operator or with operation mode selection input from the multi-function inputs.
Note If
n1
14 is set
to 1, when the operation mode changes the Inverter may start running immediately
. T
ake steps
to ensure safety for such operation.
Preparing for Operation Chapter 3
