Omron SYSDRIVE 3G3HV SERIES User Manual

5-15
D Standard Specifications and External Dimensions
200-V Class
Maximum
motor ca-
pacity (kW)
Model 3G3IV-
PUZBABj
Amperage
(A)
Inductance
(mH)
Loss (W) Weight (kg) Appearance
3.7 20 A, 0.53 MH 20 0.53 35 3
2
5.5 30 A, 0.35 MH 30 0.35 45 3
7.5 40 A, 0.265 MH 40 0.265 50 4
11 60 A, 0.18 MH 60 0.18 65 6
15 80 A, 0.13 MH 80 0.13 75 8
18.5 90 A, 0.12 MH 90 0.12 90 8
22 120 A, 0.09 MH 120 0.09 90 8
30 160 A, 0.07 MH 160 0.07 100 12
37 200 A, 0.05 MH 200 0.05 110 15
45 240 A,
0.044 MH
240 0.044 125 23
55 280 A,
0.038 MH
280 0.038 130 23
Dimensions
A B B1 C D E F H J K L M
130 88 114 105 50 65 130 22 M6 11.5 7 M5
130 88 119 105 50 70 130 22 M6 9 7 M5
130 98 139 105 50 75 130 22 M6 11.5 7 M6
160 105 147.5 130 75 85 160 25 M6 10 7 M6
180 100 155 150 75 80 180 25 M6 10 7 M8
180 100 150 150 75 80 180 25 M6 10 7 M8
180 100 155 150 75 80 180 25 M6 10 7 M10
210 100 170 175 75 80 205 25 M6 10 7 M10
210 115 182.8 175 75 95 205 25 M6 10 7 M10
240 126 218 215±5 150 110 240 25 M6 8 7 M10
240 126 218 215±5 150 110 240 25 M8 8 10 M12
Specifications Chapter 5
