6-17
Function
Refer-
ence
page
Setting
range
DescriptionNameNo.
Energy-saving
control
n095 Energy-saving
control selec-
tion
0: Inhibits the Inverter from performing en-
ergy-saving control.
1: Permits the Inverter to perform energy-
saving control.
0, 1
[0]
3-26
n096 Energy-saving
coefficient K2
Set coefficient so that maximum motor effi-
ciency will be obtained.
0.00 to
655.0
(See
note)
3-26
n097 Energy-saving
voltage lower
limit for 60 Hz
Set lower limits of energy-saving control
output voltage in 1% units at 6 Hz and
60 Hz based on motor rated voltage set
with n011 as 100%, in which case, lower
-
age will be on a straight line linking values
set with n097 and n098 if energy-saving
control output frequency is between 6 and
60 Hz.
0 to 25
[12]
3-28
n099 Mean power
time
Set time to calculate mean output power of
Inverter performing energy-saving control.
Time (ms) = 25 x n099
1 to
200
[1]
3-28
n100 Search control
voltage limit
Set range of variable voltage in 1% units to
be used by Inverter in search control mode
based on rated motor input voltage as
100%.
Search operation function will be invalid if
n101 is set to 0.
0 to
100
[0]
3-27
n101 Search control
voltage step
when 100%
Set range of variable voltage in 1% units to
be used by Inverter in search control mode
with 100% search operation start voltage
based on rated motor input voltage as
100%.
0.1 to
10.0
[0.5]
3-28
n102 Search control
voltage step
when 5%
Set range of variable voltage in 1% units to
be used by Inverter in search control mode
with 5% search operation start voltage
based on rated motor input voltage as
100%.
0.1 to
10.0
[0.2]
3-28
Not used
n103 Not used Do not change setting. 1 [1] ---
n104 Not used Do not change setting. 1 [1] ---
n105 Not used Do not change setting. 0 [0] ---
n106 Not used Do not change setting. 0 [0] ---
n107 Not used Do not change setting. 2 [2] ---
n108 Not used Do not change setting. 1 [1] ---
Note Default settings vary with the Inverter model.
Appendix Chapter 6
