Indicator Item Function
Fref Speed setting/Monitor The frequency reference can be set or monitored. The unit to
be used can be set with n024.
Fout Output frequency
monitor
The output frequency can be monitored. The setting unit can
be set with n024.
Iout Output current
monitor
The output current can be monitored in 0.1-A units.
kWout Output power monitor The output power can be monitored in 0.1-kW units.
F/R Operator
forward/reverse
selection
The forward or reverse rotation of the motor can be set or
checked. This item can be set with the Digital Operator only.
Montr Monitor selection Thirteen items can be monitored.
Accel Acceleration time
setting
Acceleration time 1 can be set or checked with n019 in 1-s
units if acceleration time 1 is set to 1,000 or a larger value and
0.1-s units if acceleration time 1 is set to a value less than
1,000.
Decel Deceleration time
setting
Deceleration time 1 can be set or checked with n020 in 1-s
units if the deceleration time is set to 1,000 or a larger value
and 0.1-s units if the deceleration time is set to a value less
than 1,000.
Vmtr Motor rated voltage
setting
The rated input voltage of the motor can be set with n011 while
the Inverter is not running.
V/F V/f pattern selection The V/f pattern can be set with n010 while the Inverter is not
running.
Fgain Frequency reference
gain
The frequency reference gain can be set with n046 while the
Inverter is not running.
Fbias Frequency reference
bias
The frequency reference bias can be set with n047 while the
Inverter is not running.
FLA Motor rated current
setting
The rated input current of the motor can be set with n032 while
the Inverter is not running.
PID PID control selection The PID control function can be selected with n084 while the
Inverter is not running.
kWsav Energy-saving control
selection
The energy-saving control function can be selected with n095
while the Inverter is not running.
PRGM Constant setting
mode
All parameters can be set or checked.
