XtraDrive User Manual Table of Contents/Preface
xiii
Using This Manual
Intended Audience
This manual is intended for the following users.
• Those designing XtraDrive XD- Series servodrive systems.
• Those installing or wiring XtraDrive XD- Series servodrives.
• Those performing trial operation or adjustments of XtraDrive XD-
Series servodrives.
• Those maintaining or inspecting XtraDrive XD- Series
servodrives.
Description of Technical Terms
In this manual, the following terms are defined as follows:
• Servomotor = SGMAH/SGMPH/SGMGH/SGMSH or other
compatible servomotor.
• Servo Amplifier = XtraDrive Series XD- servo amplifier.
• Servodrive = A set including a servomotor and servo amplifier.
• Servo System = A servo control system that includes the
combination of a servodrive with a host computer and peripheral
devices.
Indication of Inverted Signals
In this manual, the names of inverted signals (ones that are valid when
low) are written with a forward slash (/) before the signal name, as
shown in the following equations:
• S–ON = /S–ON
• P–CON = /P–CON
