XtraDrive User Manual Chapter 8 : Ratings, Specifications and Dimensional Drawings
8-8
8.4. Three-phase 400V XtraDrive and Motors Combinations
XtraDrive Model
XD-
05-** 10-** 15-** 20-** 30-**
Model SGMAH- 03D 07D — — —
Capacity (KW) 0.3 0.65 — — —
Applicable
Servomotor
Motor Speed (Rpm) Rated 3000/maximum 5000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
1.3 2.2 — — —
Maximum Output Current A
rms
5.5 8.5 — — —
SGMAH Series
(Yaskawa or compatible)
Allowable Regenerative
Frequency* (times/min)
42 15 — — —
Model SGMPH- 02D 04D 10D 15D — —
Capacity (KW) 0.2 0.4 1.0 — — —
Applicable
Servomotor
Motor Speed (Rpm) Rated 3000/maximum 5000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
1.4 1.4 2.6 4.5 — —
Maximum Output Current A
rms
4.6 4.4 7.8 13.7 — —
SGMPH Series
(Yaskawa or compatible)
Allowable Regenerative
Frequency* (times/min)
480 239 32 16 — —
Model SGMGH- 05D 09 D 13D 20D 30D
Capacity (kW) 0.45 0.85 1.3 1.8 2.9
Applicable
Servomotor
Motor Speed (rpm) Rated 1500/maximum 3000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current
A
rms
1.9 3.5 5.4 8.4 11.9
Maximum Output Current A
rms
5.5 8.5 14 20 28
SGMGH Series
-(Yaskawa or compatible)
Allowable Regenerative
Frequency
*
(times/min)
42 15 10 12 8
* Allowable regenerative frequency is the allowable frequency in the motor while accelerating and decelerating
through a 0 $ maximum motor speed $ 0(r/min) cycle.
