C.2. External Regenerative Resistors
Regenerative resistors can be externally mounted onto all XtraDrive models.
Mount a regenerative resistor externally if regenerative energy exceeds the
capacity of the XtraDrive.
If a regenerative resistor is to be mounted externally, the jumper between B2
and B3 terminals of XtraDrive must be removed.
Specifications for XtraDrive Regenerative Resistors
Specifications for Regenerative
Resistor Mounted in a XtraDrive
Applicable XtraDrive
Resistance (Ω) Capacity (W)
Min.
Allowable
Resistance
(Ω)
XD-01
XD-02
XD-04
- - 40
XD-08 50 60 40
Single-
phase
200V
XD-15 25 140 20
XD-05
XD-10
108 70 73
XD-20
Three-
phase
400V
XD-30
45 140 44
Examples of External Regenerative Resistors
Manufacturer Model Specifications Manufacturer
RH120
70W, 1 to 100
Ω
RH150
90W, 1 to 100
Ω
RH220
120W, 1 to 100
Ω
RH300C
200W, 1 to 10 k
Ω
RH500
300W, 10 to 30
Ω
Iwaki Wireless Research
Institute
* Set the resistance of the regenerative resistor to higher than the minimum allowable resistance of the
XtraDrive.
! Product Name Configurations
RH120 (N) 10 Ω J
1 2 3
1 Model N indicates non-inductive windings
2 Resistance -
3 Resistor
Tolerance
K: ±10%
J: ±5%
H: ±3%
