XtraDrive User Manual Appendix B: Special Wiring
B-10
B.4. Extending Encoder Cables
Standard encoder cables have a maximum length of 20m. If a longer cable is
required, prepare an extension cable as described below. The maximum
allowable cable length is 50m.
Preparing 50m (164.0ft) Encoder Cables
Cable Model Number: UL2076-SB
Cables are ordered in units of meters. Specify the length, when
ordering.
Connectors or Connector Kits
Connector Type Model
XtraDrive end Encoder connector (CN2) socket JZSP-CMP9-1
Encoder connector socket for SGMAH
and SGMPH servomotors
JZSP-CMP9-2
Motor end
Encoder connector plug and cable plug
for SGMGH and SGMSH servomotors
Plug
L: MS3108B20-29S
Straight: MS3106B20-29S
Cable clamp: MS3057-12A
