XtraDri
v
e User M
a
n
u
al
Appe
n
d
i
x
C
:
Spec
i
f
i
cati
o
n
s
for
P
e
rip
h
eral De
v
i
ce
s
C-14
C.11.2.
Cable wi
th RS-232 t
o RS-422 Act
ive Ad
apter
This cable is re
quired when operating XtraDrive
in Programming mode.
TXD (1)
(3) RXD
/TXD (2)
(4) /RXD
RXD (3)
(1) TXD
/RXD (4)
(2) /TXD
0V (5)
(14) 0V
FG Case FG Case
Cable Model: 004197 (YET)
9-Pin D-Sub Connector
with active ada
pter inside
14-Pin Half Pitch
Connector
Adapter
220
Ω
Cable Shield
311
313
