XtraDrive User Manual Appendix C: Specifications for Peripheral Devices

C-6

C.3. DC Reactors for Power Supplies Designed for Minimum

Harmonics

If necessary for power supplies designed for minimum harmonics, connect a

DC reactor between the (+)1 and (+)2 terminals of XtraDrive main circuits.

Select a DC reactor that matches the ratings of the XtraDrive from among

those listed in table.

DC Reactor Specifications

Reactor Specifications

Applicable XtraDrive

Impedance (mH)

Rated

Current (A)

Reactor

Model

XD-01 40.0 0.85 X5071

XD-02 20.0 1.65 X5070

XD-04 10.0 3.3 X5069

Single-

phase

200V

XD-08 4.0 5.3 X5079

XD-10 2.0 4.8 X5061

XD-20 1.5 8.8 X5060

Three-

phase

200V

XD-30 1.0 14.0 X5059

XD-05 4.7 1.5 X5074

XD-10

XD-15

3.3 4.5 X5075

XD-20

Three-

phase

400V

XD-30

2.2 8.6 X5076
