XtraDrive User Manual Chapter 8 : Ratings, Specifications and Dimensional Drawings
8-6
8.2. Single-phase 200V XtraDrive and Motors Combinations
XtraDrive Model
XD-
P3-** P5-** 01-** 02-** 04-** 08-**
Model SGMAH- A3A A5A 01A 02A 04A 08A
Capacity (KW) 0.03 0.05 0.1 0.2 0.4 0.75
Applicable
Servomotor
Motor Speed (Rpm) Rated 3000/maximum 5000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
0.44 0.64 0.91 2.1 2.8 4.4
Maximum Output Current A
rms
1.3 2.0 2.8 6.5 8.5 13.4
SGMAH Series
(Yaskawa or compatible)
Allowable Regenerative
Energy* (Joules)
18.5 37.1 ―
Model SGMPH- ― ― 01A 02A 04A 08A
Capacity (KW) ― ― 0.1 0.2 0.4 0.75
Applicable
Servomotor
Motor Speed (Rpm) Rated 3000/maximum 5000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
― ― 0.89 2.0 2.6 4.1
Maximum Output Current A
rms
― ― 2.8 6.0 8.0 13.9
SGMPH Series
(Yaskawa or compatible)
Allowable Regenerative
Energy* (Joules)
― 37.1 ―
* Allowable regenerative energy is the value with an AC input power supply voltage of 200 Vrms. The allowable
regenerative energy may vary with power supply fluctuations.
