XtraDrive User Manual Chapter 8 : Ratings, Specifications and Dimensional Drawings
8-7
8.3. Three-phase 200V XtraDrive and Motor Combinations
XtraDrive Model
XD-
08-** 10-** 20-** 30-**
Model SGMGH- ―
09A
#
A 20A
#
A 30A
#
A
Capacity (KW) ― 0.85 1.3 1.8
Applicable
Servomotor
Motor Speed (Rpm) Rated 1500/maximum 3000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
― 7.1 16.7 23.8
Maximum Output Current A
rms
― 17 42 56
Allowable Regenerative
Frequency* (times/min)
― 13 12 8
Model SGMGH-
06A
#
B 09A
#
B 20A
#
B 30A
#
B
Capacity (KW) 0.6 0.9 2.0 3.0
Applicable
Servomotor
Motor Speed (Rpm) Rated 1000/maximum 2000
Applicable Encoder
YASKAWA serial or incremental A quad B or absolute encoder.
DIFFERENT incremental A quad B encoders
Continuous Output Current A
rms
5.7 7.6 18.5 24.8
Maximum Output Current A
rms
13.9 16.6 42 56
SGMGH Series
(Yaskawa or compatible)
Allowable Regenerative
Frequency* (times/min)
39 22 20 13
* Allowable regenerative frequency is the allowable frequency in the motor while accelerating and decelerating
through a 0 $ maximum motor speed $ 0(r/min) cycle.
