XtraDrive User Manual Appendix D: List of Parameters
D-13
D.4. Output Signal Selections
The following list shows output signal selections and their default settings.
Parameter
Digit
Place
Name Setting Description
Default
Setting
0 Disabled.
1
Outputs from the SO1 (CN1-25, 26)
output terminal.
2
Outputs from the SO2 (CN1-27, 28)
output terminal.
0
/COIN Signal
Mapping
3
Outputs from the SO3 (CN1-29, 30)
output terminal.
1: SO1
1
/V-CMP Signal
Mapping
0 to 3 Same as above 1: SO1
2
/TGON Signal
Mapping
0 to 3 Same as above 2: SO2
Pn50E
3
/S-RDY Signal
Mapping
0 to 3 Same as above 3: SO3
0
/CLT Signal
Mapping
0 to 3 Same as above
1
/VLT Signal
Mapping
0 to 3 Same as above
2
/BK Signal
Mapping
0 to 3 Same as above
Pn50F
3
/WARN Signal
Mapping
0 to 3 Same as above
0
/NEAR Signal
Mapping
0 to 3 Same as above
1 Reserved 0 to 3 Same as above
0: Not
used
2 Not used. 0 — 0
Pn510
3 Not used. 0 — 0
0 Output signal is not reversed.
0
Output Signal
Reversal for
SO1 (CN-25
and 26)
1 Output signal is reversed.
0 Output signal is not reversed.
1
Output Signal
Reversal for
SO2 (CN-25
and 26)
1 Output signal is reversed.
0 Output signal is not reversed.
2
Output Signal
Reversal for
SO3 (CN-25
and 26)
1 Output signal is reversed.
0: Not
reversed
Pn512
3 Not used. — — 0
Note: 1.
When more than one signal is allocated to the same output circuit, data is output using OR logic.
2. Depending on the control mode, undetected signals are treated as OFF. For example, in the speed
control mode, the /COIN signal is treated as OFF.
3. Types of /WARN signals: Overload and regenerative overload.
D.4.1. Extended Output Signal Selection
These outputs are used in the user program.
0 Disabled.
1
Outputs from the SO1 (CN1-25, 26)
output terminal.
2
Outputs from the SO2 (CN1-27, 28)
output terminal.
0
/COIN Signal
Mapping
3
Outputs from the SO3 (CN1-29, 30)
output terminal.
0:disable
1 Not used. — — 0
2 Not used. — — 0
Pn2D2
3 Not used. — — 0
