XtraDrive User Manual Chapter 9 : Inspection, Maintenance, and Troubleshooting
9-24
! CPF01: Digital Operator Transmission Error 2
This alarm is not stored in the alarm history.
Display and Outputs
Alarm Outputs
Alarm Code Output
ALO1 ALO2 ALO3
ALM Output
Not Applicable
Status and Remedy for Alarm
During servomotor
operation.
A, B, C, D
Cause of the Problem Solution
A
Cable defective or poor contact
between digital operator and
servo amplifier.
•
Check connector
connections.
•
Replace cable.
B
Malfunction due to external
noise.
Separate digital operator and
cable from noise source.
C Digital operator defective. Replace digital operator.
D Servo amplifier defective. Replace servo amplifier.
! A.- -: Normal Operation
This is not an alarm display.
Display and Outputs
Alarm Outputs
Alarm Code Output
ALO1 ALO2 ALO3
ALM Output
OFF OFF OFF ON
Note: OFF: Output transistor is OFF (alarm state).
ON: Output transistor is ON.
To Next Page
