SOCT User Manual Version 10.0 rev. A
3D Central, align the retina between the
two dashed horizontal lines.
For all Vitreous scans, align the Vitreous
structure between the two dashed
horizontal lines.
Anterior B-Scan Angle C-Gate top, place
the angle structure below the dashed
horizontal lines.
Anterior Wide B-Scan with Two Angles,
align the two angles between the dashed
horizontal lines.
Anterior Wide B-Scan Cornea, align the
desired structure between the dashed
horizontal lines.
Biometry Axial Length, align the central
cornea reflexes with the dashed vertical
line.
Biometry ACD, align the central cornea
reflexes with the dashed vertical line.
Topography, align the desired structure
between the dashed horizontal lines and
the central cornea reflexes with the
vertical dashed line.
