Oracle Exalogic Elastic Cloud - Creating a Sub-Group for Exalogic Compute Nodes; Group Summary Screen

Figure 17-5 Group Summary Screen
4. On the Summary screen, click Finish. The Exalogic group is created at the top-
level (root).
17.9.3 Creating a Sub-Group for Exalogic Compute Nodes
After creating a top-level group for the Exalogic machine, you can create a sub-group
for Exalogic compute nodes as follows:
1.
On the right navigation pane named Actions, click Create Group under Organize.
The Configure/Modify Group screen is displayed.
2.
In the Configure Group screen, in the Group Name field, enter a name for the
new Exalogic group. For example, enter ComputeNodes. Enter a description in
the Description field. Select the Inside a user-defined Group/Subgroup option as
Location. In the Group Selection Panel, select the Exalogic top-level group that
Grouping Exalogic Machine Hardware Assets
Monitoring the Exalogic Machine Using Oracle Enterprise Manager Ops Center 17-11
