Table D-10 (Cont.) Replacement Parts for X4170 M2 Compute Nodes
Part
Number
Description Coverage
with Basic
Warranty
F375-3696 Dual port 4X QDR InfiniBand PCI-E HCA (CX2) FRU
F375-3701 6 GB/s SAS RAID HBA,Internal FRU
F371-4982 Battery for 6 GB/s SAS RAID HBA,Internal (BBU08) FRU
F540-7841 32 GB SATA SSD FRU
F300-2233 PS,AC,A247,F,12V,760W FRU
F541-4081 Motherboard (FRU'd in removable tray assembly.) FRU
F511-1489 PDB FRU
F511-1548 8 Disk BP FRU
F541-2739 PCI_BAR_1U FRU
F541-2883 PCI-E Riser, X8, 1U FRU
F541-2885 PCI-E Riser, X16, 1U FRU
F541-4275 Paddle Card, CR_FANs FRU
F530-4228 CBL,MINI-SAS,36POS,LONG,LY FRU
F530-4431 CABLE,FAN_DATA,1U FRU
F530-3927 CBL,PDB,MB,1U+2U,RIBBON FRU
F530-4417 CABLE,FAN-PADDLE BD,P FRU
F541-4276 FAN MODULE,CR,40X56 FRU
F541-4274 FAN_DECK,1U,CR_FANS FRU
F541-2075 BUSS_BAR,PWR,1U+2U FRU
F150-3993 CR2032 Battery (for M/B) FRU
For more information, see the Sun Fire X4170 M2 Server Service Manual.
D.11 Parts for Sun Network QDR InfiniBand Gateway Switch for Exalogic
X5-2
Table D-11 lists the replaceable parts for the Sun Network QDR InfiniBand Gateway
Switches used in Exalogic X5-2 machines.
Parts for Sun Network QDR InfiniBand Gateway Switch for Exalogic X5-2
Replacement Units D-11
