Table E-7 lists the InfiniBand gateway switch cross-connections for an Exalogic
machine full rack.
Table E-7 InfiniBand Gateway Switch Cross-Connections for Exalogic Machine Full
Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U16 0A U26 Sun Network
QDR InfiniBand
Gateway Switch
0A 2 meter QDR
InfiniBand cable
U16 0B U26 Sun Network
QDR InfiniBand
Gateway Switch
0B 2 meter QDR
InfiniBand cable
U16 1A U26 Sun Network
QDR InfiniBand
Gateway Switch
1A 2 meter QDR
InfiniBand cable
U16 1B U26 Sun Network
QDR InfiniBand
Gateway Switch
1B 2 meter QDR
InfiniBand cable
U16 2A U24 Sun Network
QDR InfiniBand
Gateway Switch
2A 2 meter QDR
InfiniBand cable
U16 2B U24 Sun Network
QDR InfiniBand
Gateway Switch
2B 2 meter QDR
InfiniBand cable
U16 3A U24 Sun Network
QDR InfiniBand
Gateway Switch
3A 2 meter QDR
InfiniBand cable
U16 3B U24 Sun Network
QDR InfiniBand
Gateway Switch
3B 2 meter QDR
InfiniBand cable
U23 0A U24 Sun Network
QDR InfiniBand
Gateway Switch
0A 1 meter QDR
InfiniBand cable
U23 0B U24 Sun Network
QDR InfiniBand
Gateway Switch
0B 1 meter QDR
InfiniBand cable
U23 1A U24 Sun Network
QDR InfiniBand
Gateway Switch
1A 1 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
Cabling Tables E-13
