Table E-9 (Cont.) InfiniBand Gateway Switch Inter-Connections for Exalogic
Machine Half Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U16 6B U23 Sun Network
QDR InfiniBand
Gateway Switch
6B 2 meter QDR
InfiniBand cable
E.2.3 Exalogic Machine Quarter Rack
This section contains the following tables:
• Table E-10
• Table E-11
Table E-10 lists the location, ports and cables for the InfiniBand connections for an
Exalogic machine quarter rack.
Table E-10 InfiniBand Network Cabling for Exalogic Machine Quarter Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U23 8A U22 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 8B U21 Storage appliance
server head
PCIe 0, P2 2 meter QDR
InfiniBand cable
U23 12A U9 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 12B U8 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 13A U7 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 13B U6 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
U23 14A U5 Compute node PCIe 2, P2 3 meter QDR
InfiniBand cable
InfiniBand Network Cabling Tables
E-18 Oracle Exalogic Elastic Cloud Machine Owner's Guide
