Oracle Exalogic Elastic Cloud User Manual

Table 4-4 (Cont.) Default ILOM, NET0, and IB Bonded IP for Exalogic Eighth Rack
Unit Rack Component (Front View) ILOM IP
Address
NET0 IP
Address
InfiniBand
Bonded IP
Address
3 Compute Node 192.168.1.102 192.168.1.2 192.168.10.2
2 Compute Node 192.168.1.101 192.168.1.1 192.168.10.1
1 1U Solid Filler Not
applicable
Not
applicable
Not
applicable
-
-
PDU-A (left from rear view) 192.168.1.210 Not
applicable
Not
applicable
PDU-B (right from rear view) 192.168.1.211 Not
applicable
Not
applicable
Note:
The following table shows the hardware that is included in different Exalogic
versions.
Ex
alo
gic
Ra
ck
Compute
Node’s
Server
Cisco
Management
Switch
Storage Appliance
X6
–2
Oracle
Server
X6-2
Cisco 4948E Oracle ZS5-ES
X5
–2
Oracle
Server
X5-2
Cisco 4948E Oracle ZS3-ES
X4
–2
Sun
Server
X4-2
Cisco 4948E-
F-S
Oracle ZS3-ES
X3
–2
Sun
Server
X3-2
Cisco 4948E-
F-S
Sun ZFS 7320
X2
–2
Sun Fire
X4170
M2
Cisco 4948 Sun ZFS 7320
4.5 Default Port Assignments
Table 4-5 lists the default ports assigned to Exalogic compute nodes and other
hardware components in an Exalogic machine.
Default Port Assignments
4-12 Oracle Exalogic Elastic Cloud Machine Owner's Guide
