Table E-2 (Cont.) Gigabit Ethernet Cabling for Exalogic Machine Half Rack
From
Rack Slot
Type of Equipment From
Equipment
Port
To
Cisco
Switch
Port
Description
U4 Compute node NET0 35 10' Blue Cat 5
U3 Compute node NET0 36 10' Blue Cat 5
U2 Compute node NET0 37 10' Blue Cat 5
U1 Sun Datacenter InfiniBand
Switch 36
NET0 42 7' Black Cat 5
Table E-3 shows the cable connections from the compute nodes to the Gigabit Ethernet
switch (Cisco switch) in an Exalogic machine quarter rack:
Table E-3 Gigabit Ethernet Cabling for Exalogic Machine Quarter Rack
From
Rack Slot
Type of Equipment From
Equipment
Port
To
Cisco
Switch Port
Description
Not
applicable
External LAN NET 1 10' Blue Cat 5
Not
applicable
PDU-A NET 2 1M Grey Cat 5
Not
applicable
PDU-B NET 3 1M Grey Cat 5
U23 Sun Network QDR InfiniBand
Gateway Switch
NET0 40 7' Black Cat 5
U22 Storage appliance server head NET0 20 7' Blue Cat 5
U22 Storage appliance server head NET1 21 7' Blue Cat 5
U22 Storage appliance server head NET2 43 7' Blue Cat 5
U21 Storage appliance server head NET0 22 7' Blue Cat 5
U21 Storage appliance server head NET1 23 7' Blue Cat 5
U21 Storage appliance server head NET2 44 7' Blue Cat 5
U16 Sun Network QDR InfiniBand
Gateway Switch
NET0 41 7' Black Cat 5
U9 Compute node NET0 30 10' Blue Cat 5
U8 Compute node NET0 31 10' Blue Cat 5
U7 Compute node NET0 32 10' Blue Cat 5
U6 Compute node NET0 33 10' Blue Cat 5
Administrative Gigabit Ethernet Network-Cabling Tables
Cabling Tables E-5
