Table E-13 InfiniBand Gateway Switch Inter-Connections for Exalogic Machine
Eighth Rack
From
Rack Unit
(Sun
Network
QDR
InfiniBand
Gateway
Switch)
Port To Rack
Unit
Type of
Equipment
Port Description
U16 4A U23 Sun Network
QDR InfiniBand
Gateway Switch
4A 2 meter QDR
InfiniBand cable
U16 4B U23 Sun Network
QDR InfiniBand
Gateway Switch
4B 2 meter QDR
InfiniBand cable
U16 5A U23 Sun Network
QDR InfiniBand
Gateway Switch
5A 2 meter QDR
InfiniBand cable
U16 5B U23 Sun Network
QDR InfiniBand
Gateway Switch
5B 2 meter QDR
InfiniBand cable
U16 6A U23 Sun Network
QDR InfiniBand
Gateway Switch
6A 2 meter QDR
InfiniBand cable
U16 6B U23 Sun Network
QDR InfiniBand
Gateway Switch
6B 2 meter QDR
InfiniBand cable
U16 USB Serial Not
applicab
le
Open ended Not
applicable
USB Adapter
U16 USB Serial Not
applicab
le
Open ended Not
applicable
USB Adapter
E.3 Power Distribution Unit Cabling Tables
This section contains the tables for the Power Distribution Units (PDU) cabling for
Exalogic Elastic Cloud.
This section contains the following topics for Single Phase PDUs:
• Single Phase PDU Power Cabling Full Rack
• Single Phase PDU Power Cabling Half Rack
• Single Phase PDU Power Cabling Quarter Rack
• Single Phase PDU Power Cabling Eighth Rack
Power Distribution Unit Cabling Tables
E-22 Oracle Exalogic Elastic Cloud Machine Owner's Guide
